I 2 C? Master Communications
FIGURE 4-3:
I 2 C? BASIC OPERATIONS
4.7
SCRIPT BUILDER
I 2 C commands can be combined into scripts, saved, and used over again. The Script
Builder window is opened by selecting Communications > Script > Script Builder from
the menu bar. The Script Builder is shown in Figures 4-4.
The Script Builder window is divided into four columns as shown in Figures 4-5 through
4-8.
FIGURE 4-4:
I 2 C? SCRIPT BUILDER
4.7.1
Script Commands
The left most column contains the Script Commands as shown in Figures 4-5.
? Script Name – Enter the name of the script
? Save Script – Saves the script
? Execute Script – Executes (performs) the script displayed in the Script Detail
column
? Clear Script – Clears the Script Detail column
? Del User Scripts – Deletes scripts from the User Scripts column.
? Show Array – Displays a spreadsheet-like table in which large amounts of data
may be entered. This data can be included in the script by right clicking in a Script
Detail cell and choosing “Insert Array”.
? 2007 Microchip Technology Inc.
DS51647A-page 31
